Carpentry Tools
- Broadax
- 1998.23.2
- Broadax head
- Broadax head with one flat side and a single beveled blade for right hand use. Broadaxes were used to hew a flat plane on a log or to make square timbers.... View Full Record
- Hatchet, Hewing
- 1991.98.5
- Frank DeKelver's broad hatchet
- Broad hatchet with one flat surface enabling blade to swing flush along a surface for shaping, dimensioning, and smoothing wood. It is possible this tool was used in the building of the F. J. DeKelver's Exchange Hotel in the village of Pike.... View Full Record
- Hatchet
- 1991.98.15
- Frank Dekelver's Half Hatchet.
- A half hatchet with a blade at one end and a hammer head on the other. The blade is notched for pulling nails. It is possible this tool was used in the building of the F. J. DeKelvers Exchange Hotel in the village of Pike.... View Full Record
- Hatchet, Claw
- 0011.10.11
- Claw hatchet
- Claw hatchet with doubled flared head and a claw at the opposite end for pulling out nails.... View Full Record
- Drawknife, Carpenter's
- 1991.98.3
- Frank DeKelver's drawknife
- Drawknife with two hand carved handles and with what appears to be a blade forged by a blacksmith. It is possible this tool was used in the building of the F. J. DeKelver's Exchange Hotel in the village of Pike.... View Full Record
- Drawknife
- 1991.98.4
- Frank DeKelver's draw knife
- A drawing knife with a fourteen inch slightly curved blade and two slightly turned down wood handles. Draw knives are used to shape wood by removing shavings. The knife is drawn toward the user. The narrow blade assists in creating concave or convex... View Full Record
- Spokeshave
- 1991.99
- Wooden drawknife
- A wooden spokeshave with three and one-half inch metal beveled blade that is moved up and down by tapping the tangs to regulate the depth of cut.... View Full Record
- Drawknife, Chamfering
- 1999.9
- Chamfer knife
- The chamfer knife has one wood handle and one steel. It was used to chamfer the edges on the ends of barrels.... View Full Record
- Saw, Bow
- 1999.5.1
- Bow saw
- With a bow saw tension is applied to the blade by twisting the cord at the top of the saw and securing the wood rod to the cross brace. The saw blade was easily turned making it easy to cut curved surfaces.... View Full Record
- Saw, Frame
- 1991.57
- Turning Saw
- The frame saw later has a wing nut on a rod at the top of the frame to adjust the tension of the blade. The saw has a wood frame. A frame saw was used to make intricate cuts in woodworking or carpentry.... View Full Record
- Saw, Hand
- 1991.98.10
- Frank Dekelver crosscut handsaw
- Crosscut carpenter handsaw with wood handle.... View Full Record
- Saw, Woodworking
- 0011.11.6
- Shapleigh No. 150 handsaw
- Handsaw with blade of spring steel with six points per inch designed for ripping boards lengthwise with wood handle.... View Full Record
- Plane, Jack
- 2004.16.2
- A. C. Bartlette jack plane
- Plane consists of a wood block with a mortise cut across the center of the body to hold cutting blade. Cutting blade is held in place with a wood wedge. The jack plane is used for straightening the edges of boards, sizing stock, or jointing edges.... View Full Record
- Plane, Smoothing
- 2004.16.3
- Smoothing plane
- A smoothing plane is bench plane that was used for the final finish on a wood surface. The cutting edge is usually slightly curved to prevent gouging the wood.... View Full Record
- Plane, Jointer
- 1991.98.2
- Baldwin box plane
- Plane consists of a wood block with a mortise cut across the center of the body to hold cutting blade. Cutting blade is held in place with a wood wedge. The long length of a jointer plane is designed for straightening the edges of boards. It is pos... View Full Record
- Square, Carpenter's
- 1991.98.8
- Frank DeKelver's carpenter's square
- Steel carpenter's square marked in inches on both sides and arms of square used to lay out a square or right angle.... View Full Record
- Level, Carpenter's
- 0011.11.12
- Pocket level
- Pocket level with screw for quick attachment of a carpenter's square or straight edge.... View Full Record
- Level, Plumb
- 0011.11.18
- Brass plumb level
- Brass plumb level with steel tip and removable brass knob at top to attach string.... View Full Record
- Level, Carpenter's
- 0010.5
- Carpenter's level
- Wood level with brass ends, brass plate to hold level in place, and press plate with adjusting screw.... View Full Record
- Toolbox
- 0011.11.22
- John Beck's toolbox
- Toolbox with wood handle to carry tools to work site.... View Full Record
- Square, Bevel
- 0011.11.4
- Sliding "T" Bevel
- Sliding "T" bevel with rosewood handle, brass tipped with brass adjusting screw and steel blade.... View Full Record
- Square, Try
- 0011.11.5
- Try square
- Brass lined rosewood handle with graduated steel blade.... View Full Record
- Plane, Plow
- 0011.11.23
- A. C. Bartlett's plow plane
- A. C. Bartlett plow plane with set of 7 blades made by the Sandusky Tool Co.... View Full Record
- Plane, Tongue and Groove
- 0011.11.7
- Set of tongue and groove planes
- A matched set of two hand planes; one created a groove and the other a tongue; the tongue cut on one board fits into the groove on another to perfectly join the two board together.... View Full Record
- Plane, Hollow
- 0011.11.8
- Molding planes
- Set of four hollow molding planes.... View Full Record
- Plane, Rabbet
- 0011.11.9
- Rabbet planes
- Set of two rabbet planes.... View Full Record
- Bit, Gimlet
- 0011.11.11
- Gimlet with wood handle
- Gimlet bit with wood handle and a screw thread and cutting blade at the tip for drilling a small hole to start screws.... View Full Record
- Drill, Hand
- 0011.11.3
- Ratcheting bit brace
- Ratchet bit brace with ten inch sweep, wood head and handle. Ringed ratchet controls direction that bit turns.... View Full Record
- Bit, Drill
- 0011.11.10
- Auger bits
- Set of auger bits starting with a number 4 to a number 16 used to bore holes in wood. The tapered four sided ends were designed to fit a hand bit brace.... View Full Record
- Saw, Keyhole
- 1991.98.14
- Frank DeKelver's keyhole saw
- A keyhole saw with a wood carved handle and a triangular blade for cutting circles and curves in wood. It is possible this tool was used in the building of the F. J. DeKelvers Exchange Hotel in the village of Pike.... View Full Record
- Divider
- 0011.11.13
- Divider
- Metal divider with graduated scale with a fine adjustment and a set screw to hold pointed arms in place.... View Full Record
- Gauge, Marking
- 0011.11.14
- Wooden marking gauge
- Wooden marking gauge with brass thumbscrew, brass plate on head, and steel marker on end of arm.... View Full Record
- Rule, Folding
- 0011.11.19
- Lufkin Folded Ruler
- Wood folding rule with brass ends and an inlay brass six inch brass rule with steel spring joints. Numbers are black lettered with every 16 inch multiple marked in red.... View Full Record
- Slick
- 1991.98.6
- Frank DeKelver's slick
- A wood slick with a slightly curved blade and a hardwood socketed handle. A slick is pushed by bracing the handle against a shoulder or upper arm to make fine paring cuts. Slicks were used for timber framing. It is possible this tool was used in the... View Full Record
- Chisel, Woodworking
- 0011.11.15
- John Beck's chisels
- Six woodworking chisels with square edges and wood handles some with steel ends and one with a brass end.... View Full Record
- Gouge, Woodworking
- 0011.11.16
- John Beck's gouges
- Set of three woodworking gouges with wood handles.... View Full Record
- Mallet, Carpenter's
- 0011.11.1
- Hickory carpenter's mallet
- Hickory square headed mallet with mortised handle.... View Full Record
- Mallet, Carpenter's
- 0011.11.2
- Rawhide carpenter's mallet
- Carpenter's mallet with round head made of rolled rawhide leather with wood handle.... View Full Record
- Puller, Nail
- 0011.4
- Suregrip nail puller
- Suregrip No. 56 cast iron nail puller.... View Full Record
- Plane, Combination
- 1997.26.2
- Stanley combination plane
- A combination wood plane that originally came with a set of eleven cutters that enabled it to be used as a plow, dado, filletster, or rabbet plane.... View Full Record
